8 Outputs DTT-SAT Tap F 15dB Tecatel

SKU
TECDERCLA8S15
Brands: Tecatel
€7.39 Tax included
Availability: In stock
24/48 Hours

8 outputs DTT-SAT Tap F -15dB Tecatel DER-CLA8S15

DTT-SAT F connection tap for distribution of 8 outputs per plant with 15dB of derivation and 4dB of step. Manufactured in armored Zamak box with an anticorrosive nickel finish.

The taps are used in collective TV installations of ICT regulations, they are located in the building's backbone network and their function is to distribute the signal to each house per floor, they have a pass-through output with less attenuation to carry the input signal to the derivative of the lower floor.

-
+

DTT-SAT Tap with 8 F-type outputs with 15dB attenuation, for ICT collective installations

What technical specifications does the Tecatel DER-CLA8S15 Tap have?

  • Reference: DER-CLA8S15
  • Shunt losses:
    • 5-1000 MHz: 15 ± 1 dB
    • 1000-2400 MHz: 15 ± 1.5 dB
  • Insertion losses:
    • 5-47 MHz: 3.9 dB
    • 47-1000 MHz: 4.4 dB
    • 1000-1750 MHz: 4.5 dB
    • 1750-2300 MHz: 4.8 dB
    • 2300-2400 MHz: 5 dB
  • Pass-by-pass isolation:> 18 dB
  • Dimensions: 124x60x26 mm
  • Weight: 118 gr.
  • Frequency range: 5-2400 MHz
  • Impedance: 75Ω
  • Connectors: F
More Information
EAN 8430549029125
Hight 0.100
Length 0.030
Width 0.070
DTT System DTT & SAT Distribution
MANUFACTURER SERIES DTT F-connector
TV-SAT Distribution Equipment Diverter
Entorno Interior
TV-SAT Distribution Connection F
Outputs 8
Insertion Loss (dB) 15
Product Brand Tecatel
