Fagor FMC 5 Series 5x32 Terminal Multiswitch with Power Supply

SKU
FAG86464
Brands: Fagor
€330.35 Tax included
Free shipping
(Iberian Peninsula)
Fagor
Availability: On request
1 to 7 days

Multiswitch FMC 532 with Power Supply from Fagor

This cascade multiswitch distributes 4 satellite polarities and 1 terrestrial input. With only one coaxial cable we can transport to each user both the satellite signal and the terrestrial signal, so that each user can access independently to any of the satellite polarities.

This multiswitch has low losses, its terrestrial signal input is active and compatible with digital terrestrial emissions (COFDM). It supports DiSEqC 2.0-2.1 commands. In addition, it has voltage/tone control (22KHz) from the user's receivers. The receiver, depending on the TV channel selected by the user, will send a voltage across the coaxial cable for polarization (14Vdc for vertical and 18Vdc for horizontal) and a tone for the band (0KHz for low and 22KHz for high).

Compatible with LNB Quattro and LNB Quad. The multiswitch allows each house to have access to the radio signal, DTT and all satellite polarities, without having to install a satellite dish per user.

Technical Specifications of the Fagor FMC 532 Multiswitch with Power Supply

MODEL FMF 532
Reference 86464
Inputs 4 SAT + 1 TERR
User outputs 32
TERR dB range 70÷862
SAT frequency 950÷2150
TERR
SAT dB bypass
-3 ± 2
-2÷2 (±2)
TERR
SAT dB gain
-
SAT-SAT >40
SAT-TERR isolation dB >35
OUT-OUT >35
SAT max output level dBμV (SAT-35dB IM3) 102
Satellite and polarity selection 13 Vdc / 18 Vdc - 0 / 22 KHz
DiSEqC 2.0-2.1
Consumption (without LNB) mA 300
Power supply Vac 195-265 Vac / 18Vdc / 2.5 A
Operating temperature ºC -10 a 40
Packaging dimensions mm 233 x 350 x 50
Weight Kg 1,35
More Information
Hight0.350
Length0.020
Width0.300
System SATSAT Multiswitch
SERIE SATF Connector
ColorBlack
TypeAmplifier
# Input satellites4
# Terrestrial inputs1
#User outputs32
Product BrandFagor
