Keynet UTP CAT6A Cable White Cu CCA LSZH Coil 305m

Name: Keynet UTP CAT6A Cable White Cu CCA LSZH Coil 305m
Brand: Keynet
SKU: KEYCAT6AUTP305
Price: 354.29 EUR
Availability: InStock

SKU

KEYCAT6AUTP305

Brands: Keynet

€354.29 Tax included

Availability: On request

Delivery: 1 to 7 days

Be the first to review this product

UTP CAT6 Cable White Cu Cca LSZH Interior in 305 meter Keynet Reel

305 meter UTP data cable coil. This data cable is category 6A, has crosshead and tear wire and 23AWG rigid conductors.

The Ethernet cable complies with the IEEE802.3bt PoE type 4 standard. This cable is used for voice, data and image transmission up to 550MHz, supporting speeds up to 10Gigabit. This cable is perfect for the installation of data networks, such as internet connection, camera installations or intercom and video intercom installations.

The cable has a smooth round halogen-free (LSZH) jacket with Euroclass CPR Cca in white color. This cable does not have any shielding.

The cable has a 25-year warranty.

Details

Technical Specifications of the UTP CAT6 Indoor White Cu Cca LSZH Cable in a 305-meter Keynet Coil

Reference					ľD-625AUT-C3-LBR-W
Setting up					Cat 6A U/UTP
Conductor	AWG				23 AWG / 0,560 ± 0,01
	Material				BC / Cobre puro
Isolation	Material				HDPE
	Diameter			mm	1,01 ± 0,02
External cover	Thickness			mm	0,7
	External diameter			mm	7,1 ± 0,5
	Material				LSZH
	CPR				Cca-s1a,d1,a1
	Coloí				Blanco RAL 9010
Cross-piece					Sí (HDPE)
Torn Thread					Sí
Frequency range			MHz		1 - 550
Impedance			Ω		100 ± 15
Mutual nominal capacity			pF/100m		5600
Maximum unbalanced capacity			pF/100m		≤ 160
Maximum continuous current resistance			Ω/100m		≤ 9,5
Nominal propagation speed NVP			% v.l.		68
Differential delay (skew)			ns/100m		≤ 45
Maximum unbalanced continuous current resistance					≤ 2,5%
PoE Compliance					IEEC802.3bt PoE type 4 (90 Watts)
Tensile strength before aging		Mpa			≥ 13,5
Stretching before aging		%			≥ 150
Tensile strength after aging		Mpa			≥ 12,5
Stretching after aging		%			≥ 125
Pair 1						Blue
Pair 2						Orange
Pair 3						Green
Pair 4						Brown

More Information

More Information
Hight	0.360
Length	0.370
Width	0.360
System DTT	CAT6A
Serie	305m
Entorno	Exterior
Color	White
Cobertura Exterior Cables	LSFH
Conductor Interno Cables	Copper Clad Aluminum (CCA)
Product Brand	Keynet
