UAP Splitter EasyF 3D 7dB Televes

Name: UAP Splitter EasyF 3D 7dB Televes
Brand: Televes
SKU: TEL543902
Price: 12.25 EUR
Availability: InStock

SKU

TEL543902

Brands: Televes

€12.25 Tax included

Availability: On request

Delivery: 1 to 7 days

Be the first to review this product

UAP 3-way splitter type Televes Flange 543902

UAP Splitter unit with DTT-SAT (5-2400Mhz), with 3 "EasyF" flange outputs with 7dB of medium attenuation.

The User Access Points are passive distribution equipment with an additional entrance loaded to connect the second downspout in an installation carried out according to the ICT-2 regulation. All also have DC current pass from the outputs to the input.

For indoor installation. Suitable for outside in a 4177 Televes chest.

Details

Technical Specifications of Televes PAU Distributor 3 Outputs 543902

Frequency range		MHz	5-2400
			5-862	950-2400
Number of outputs			3
Through loss	S1/S2	dB	9	8
	S3/S4		5	4
	S5/S6		-	-
	S7/S8		-	-
Tap loss			>17	>15
DC Pass (max.)		mA	300 (in.↔out.)

More Information

More Information
EAN	8424450143759
Hight	0.090
Length	0.152
Width	0.065
DTT System	DTT & SAT Distribution
SERIES DTT	Brida Connector
Color	Silver
TV-SAT Distribution Equipment	UAP
Entorno	Interior
TV-SAT Distribution Connection	Flange
Product Brand	Televes
