UPS Blazer MP1500 1500VA/900W NEW UPS

SKU
SAI13150
Brands: NEW-SAI
€242.24 Tax included
Free shipping
(Iberian Peninsula)
Availability: On request
1 to 7 days

UPS Blazer MP1500 1500VA/900W LCD 2xschucko+IEC+RS232+USB

The new line-interactive Blazer UPS range has the best features on the market with state-of-the-art microprocessor control. Designed to protect computing devices against power outages, power surges or overloads.

With a power of 1500VA and 900W, this power supply system has a range of up to 10 minutes. The device has 2 Schucko outputs and 2 x IEC. Its batteries are quickly charged from 910% with charge in 6-8 hours, in addition to charging them with the equipment stopped in OFF mode.

It has an LCD screen that displays a large amount of information, such as the status of input data such as consumption, voltage, battery voltage or UPS load level.

Microprocessor controlled that guarantees high reliability. Includes USB communication AND RJ-11 port for telephone protection. You can control the UPS by software through the RS232 port.

Suitable for the connection of up to 3 PCs + Monitor. The connection of laser printers is not recommended, since they damage the batteries due to the consumption peaks they have (in the case of matrix printers there is no problem).

-
+

Technical Specifications of the UPS Blazer MP1500 1500VA/900W LCD 2xschucko+IEC+RS232+USB



Description
The NEW UPS Blazer MP MicroPower range of 1000/1500/2000/2400/3000 are Line Interactive UPSs with a microprocessor control design including the dynamic control of the AVR booster, it has cold start functions and an RS232 or USB interface port In short, it is the ideal solution at the lowest cost for sensitive equipment with critical missions.
PC's and their peripherals. As a novelty, this range of models is capable of working with some generators on the market.
Specs
MODEL BLAZER MP                      MP 1000 CODE                                    13100 MP 1500
13150
MP 2000
13200
MP 2400
13240
MP 3000
13300
POWER 1000VA / 600W 1500VA / 900W 2000VA / 1200W 2400VA / 1440W 3000VA / 1800W
INPUT
Voltage
Voltage Range Frequency Range
110/120 VAC or 220/230/240 VAC
81-145 VAC / 162-290 VAC
60/50 Hz (auto detection)
OUTPUT
AC Voltage Regulation (Battery Mode) DC Voltage Option (USB)
Frequency Range (Battery Mode)
Transfer Time Wave Type (Battery Mode)
±1%
5V
60 Hz or 50 Hz ±1 Hz Typical 2-6 ms, maximum 10 ms.
Simulated sinusoidal
BATERIAS
Batteries Type and Number
Autonomy Time (Load 2PC 150 W) Typical Recharge Time
12 V/7 Ah x 2
10 min.
12 V/9 Ah x 2
10 min.
12 V/9 Ah x 2
8 min.
12 V/7 Ah x 4
20 min.
12 V/9 Ah x 4
25 min.
6 - 8hours recovers up to 90% of the capacity
INDICATORS
AC mode
Battery Mode Fault Mode
lit green
Blinking Amber On Red
PROTECTION
Full Protection Protection against Overload, Discharge and battery overcharge
ALARMS
Battery mode
Low Battery Overload
Battery Replacement Fault Alarm
Beep every 10 seconds Beep every second Beep every 0.5 seconds Beep every 2 seconds
Continuous beep
PHYSICAL
Dimensions, D X W X H (mm)
Net weight(kgs)
338 X 162 X 150 380 X 158 X 198 436 X 145 X 213
13 14 15 20 23
OPERATING ENVIRONMENT
Humidity
Noise level
0-90 % RH @ 0- 40°C (non-condensed)
Less than 40dB
CONTROL SOFTWARE
Optional USB / RS-232 ports Windows family, Linux, Sun Solaris, IBM AIX, Unix, Compaq True64, SGIIRIX, FreeBSD, HP-UX, Mac
More Information
Hight 0.280
Length 0.450
Width 0.220
RED - System Red
RED - SERIE power supply
Color Black
Network Equipment UPS
Ports 2
PoE No
Product Brand NEW-SAI
Write Your Own Review
You're reviewing:UPS Blazer MP1500 1500VA/900W NEW UPS
Your Rating
File Label Size Download
pdf Ficha Técnica del SAI Blazer MP1500 1500VA/900W LCD 2xschucko+IEC+RS232+USB 164.8 KB Download
