Ajax Roller shutter controller series Walli Anthracite

SKU
FIBFGWREU1118
Brands: Fibaro
€76.23 Tax included
Fibaro
Availability: In stock
24/48 Hours

Mechanism for blinds series Walli Anthracite FGWREU-111-8 EU

Fibaro Walli Switch series device controller is an elegant and sophisticated configurable smart wall switch, it is designed to control awnings, venetian blinds, roller shutter motors by AC via Z-Ware network.

Its LED ring adapts to you, being able to configure it with your favorite color. You can choose a base color for the switch, choose double backlighting, being able to use two colors of the ring (for ON and OFF or to know the status of the device). You can also know the energy consumption of your domestic equipment, according to a color scale.

The connection is made through the Z-Wave protocol,it is an international standard for the interconnection of wireless home automation systems, which makes it compatible with the rest of the Fibaro devices.

Package content:

*FGWREU-111-AS-8001 switching unit

*Single cover plate FG-Wx-PP-0001

*Switch button with light guide FG-WDSEU221-AS-8100

*FIBARO FG-Wx-AS-4004 mounting frame

*Manual

Technical Specifications of the Fibaro Walli Roller Shutter ANTHRACITE FGWREU-111-8 EU



Brand: Fibaro

Dimensions: 86x86x51mm

POWER AND INSTALLATION

Power supply: 110-230V 50/60Hz

Recommended external overcurrent protection: 10A type B

Active element: micro-gap relay

Switch: electronic or mechanical

For installation in flush-mounted boxes:

Ø = 60mm
Depth ≥ 40mm

Operating temperature: 0-35ºC

Environmental humidity: 10-95% Non-condensing.

DEVICE APPLICATIONS

Rated charging current:

*13A for resistive loads

*4A for power factor compensated motors

Compatible Load Types:

*Single phase AC motors

*resistance

COMMUNICATIONS

Radio Protocol: Z-Wave

Transmission power: EIRP max. 6dbm

Radio frequency:

*868.4 or 869.85 MHz EU

*869.0 MHz UK

Range:

*up to 50m outdoors

*up to 40m indoors (depending on terrain and building structure).

More Information
EAN5902701702380
Hight0.120
Length0.040
Width0.100
SECURITY - SYSTEMZ-Wave
SEGURIDAD - SERIEWalli
ColorBlack
AutomationButton / Switch
Product BrandFibaro
