System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web; Local GUI
|
|
Quick Pick
|
|
QuickPick 2.0 AI by Recorder (Number of Channels)
|
2 channels
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
Advanced Mode: 2 channels, 10 IVS rules for each channel
General Mode: 8 channels, 10 IVS rules for each channel
|
|
Face Detection
|
|
Face Attributes
|
6 attributes
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
2 channels(up to 12 face images/s each channel)
|
|
Privacy Protection
|
|
Privacy Protection Performance of AI by Recorder (Number of Channels)
|
1 channel
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 10 face databases with 20,000 images.
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
2 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
16 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change
|
|
SMD Plus by Camera
|
32 channels
|
|
AI Video Quality Analytics
|
|
AI Video Quality Analytics by Recorder
|
16 channels: Supports detecting brightness levels, color cast, defocus, overexposure, contrast levels, black and white
|
|
Scene Changing
|
|
Scene Changing by Recorder
|
1 channel
|
|
Irregular Black Block Masking
|
|
Irregular Black Block Masking by Recorder
|
1 channel
|
|
Audio and Video
|
|
Analog Camera Input
|
16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
|
|
Camera Input
|
1. CVI: 4K@25/30 fps; 4K@12.5/15 fps; 6 MP@20 fps; 5 MP@25 fps; 5 MP@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.
2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.
3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.
|
|
IP Camera Input
|
Up to 32 channels of IPC access
16 IP channels by default + 16 channels (analog channels are converted to IP channels)
Incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
*After IP extension is enabled, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, SMD, Perimeter Protection, QuickPick 2.0 and Privacy Protection cannot be used.
|
|
Encoding Capacity
|
Encode Enhancement disabled：
Main stream:
4K@(1 fps–7 fps); 6 MP@(1 fps–10 fps); 5 MP@(1 fps–12 fps); 4K-N/4 MP/3 MP@(1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF@(1 fps–25/30 fps)
Sub stream:
960H@(1 fps–15 fps); D1/CIF@(1 fps–25/30 fps)
Encode Enhancement enabled：
Main stream:
the 1st, 5th, 9th, 13th channel 4K@(1 fps–15 fps), others 4K@(1 fps–7 fps);
the 1st, 5th, 9th, 13th channel 6 MP@(1 fps–20 fps), others 6 MP@(1 fps–10 fps);
the 1st, 5th, 9th, 13th channel 5 MP@(1 fps–25 fps), others 5 MP@(1 fps–12 fps);
the 1st, 5th, 9th, 13th channel 4K-N/4 MP/3 MP@(1 fps–25/30 fps), others 4K-N/4 MP/3 MP@(1 fps–15 fps);
4K/6 MP@(1 fps–10 fps);5 MP@(1 fps-12 fps); 4K-N/4 MP/3 MP@(1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF@(1 fps–25/30 fps)
Sub stream:
960H@(1 fps–15 fps); D1/CIF@(1 fps–25/30 fps)
*When Encode Enhancement is enabled, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, Perimeter Protection, QuickPick 2.0 and Privacy Protection cannot be used.
|
|
Dual-stream
|
Yes
|
|
Video Bit Rate
|
32 kbps–6144 kbps
|
|
Audio Sampling
|
8 kHz, 16 bit
|
|
Audio Bit Rate
|
64 kbps
|
|
Video Output
|
1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.
|
|
Multi-screen Display
|
When IP extension mode not enabled: 1/4/8/9/16
When IP extension mode enabled: 1/4/8/9/16/25/36
|
|
Third-party Camera Access
|
Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF
|
|
Compression Standard
|
|
Video Compression
|
AI Coding; Smart H.265+; H.265; Smart H.264+; H.264
|
|
Audio Compression
|
G.711a; G.711u; PCM
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
|
|
Mobile Phone Access
|
iOS; Android
|
|
Interoperability
|
ONVIF 23.12 (Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome; IE; Safari; Edge; Firefox
|
|
Recording Playback
|
|
Record Mode
|
General; alarm; motion detection; intelligent; POS
|
|
Recording Playback
|
1/4/9/16
|
|
Backup Method
|
USB device and network
|
|
Playback Mode
|
Instant playback; general playback; event playback; tag playback; smart playback
|
|
Alarm
|
|
General Alarm
|
Motion detection; alarm box; HDCVI alarm; camera external alarm; network alarm; PIR alarm
|
|
Anomaly Alarm
|
Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline
|
|
Intelligent Alarm
|
Face detection; face recognition; perimeter protection; SMD Plus
|
|
Alarm Linkage
|
Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email
|
|
Ports
|
|
Audio Input
|
1-channel RCA
16-channel BNC (Coaxial Audio)
|
|
Audio Output
|
1-channel RCA
|
|
Two-way Talk
|
Yes (share the same audio input with the first channel)
|
|
Disk Interface
|
1 SATA port, up to 16 TB. This limit varies depending on the environment temperature.
|
|
RS-485
|
1
|
|
USB
|
2 (1 front USB 2.0 port, 1 rear USB 3.0 port)
|
|
HDMI
|
1
|
|
VGA
|
1
|
|
Network Port
|
1 (10/100/1000 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
12 VDC, 3 A
|
|
Power Consumption
|
<15 W (without HDD)
|
|
Net Weight
|
1.30 kg (2.87 lb)
|
|
Gross Weight
|
2.10 kg (4.63 lb)
|
|
Product Dimensions
|
325.0 mm × 257.1 mm × 55.0 mm (12.80" × 10.12" × 2.17") (W × D × H)
|
|
Packaging Dimensions
|
372.0 mm × 117.0 mm × 308.0 mm (14.65" × 4.61" × 12.13") (W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to +131 °F)
|
|
Storage Temperature
|
–20 °C to +60 °C (–4 °F to +140 °F)
|
|
Operating Humidity
|
10%–90% (RH), non-condensing
|
|
Installation
|
Desktop
|
|
Certifications
|
CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B
|
