System
|
|
Main processor
|
Industrial grade processor
|
|
Operating system
|
Embedded Linux
|
|
Operating interface
|
Web; GUI local
|
|
Perimeter protection
|
|
AI Edge Performance per Recorder (Number of Channels)
|
Advanced model: 2 channels, 10 IVS rules for each channel General model: 4 channels, 10 IVS rules for each channel
|
|
Face detection
|
|
Attributes of the face
|
6 attributes
|
|
AI face detection performance per recorder (number of channels)
|
1 channel (up to 8 face images/s per channel)
|
|
Facial recognition
|
|
Face database capacity
|
Up to 10 face databases with 10,000 images.
|
|
AI facial recognition performance per recorder (number of channels)
|
1 canal
|
|
SMD plus
|
|
SMD Plus Recorder
|
4-channel: Secondary filtering for people and motor vehicles, reducing false alarms caused by leaves, rain, and changes in lighting conditions.
|
|
Audio and video
|
|
Analog camera input
|
4 BNC ports, support HDCVI/AHD/TVI/CVBS auto-detection
|
|
Camera input
|
1. CVI: 5 MP a 20 fps, 5 MP a 25 fps, 5 MP a 10/12,5 fps, 4 MP a 25/30 fps, 1080p a 25/30 fps, 720p a 50/60 fps, 720p a 25/30 fps. 2. TVI: 5 MP a 20 fps, 4 MP a 25/30 fps, 1080p a 25/30 fps, 720p a 25/30 fps. 3. AHD: 5 MP a 20 fps, 4 MP a 25/30 fps, 1080p a 25/30 fps, 720p a 25/30 fps.
|
|
IP camera input
|
Up to 6 IPC access channels 2 IP channels by default + 4 channels (analog channels are converted to IP channels) incoming bandwidth: 32Mbps, recording bandwidth: 32Mbps and outgoing bandwidth: 32Mbps *After adding IP channels beyond the existing channels, the AI function (IVS, SMD, Face) will be disabled.
|
|
Coding capacity
|
Main Stream: 5MP Mode: All 5MP Channels @ (1-6 fps) 5M-N Mode: All 5M-N Channels @ (1-12 fps); 4M-N, 1080p @ (1-15 fps); 1080N, 720p, 960H, D1, CIF @ (1-25/30 fps) Sub Stream: D1, CIF @ (1-15 fps)
|
|
Dual transmission
|
Yeah
|
|
Video bitrate
|
32 kbps–6144 kbps
|
|
Audio sampling
|
8 kHz, 16 bits
|
|
Audio bit rate
|
64 kbps
|
|
Video output
|
1 HDMI, 1 VGA HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
|
|
Multi-screen display
|
When IP extension mode is not enabled: 1/4 When IP extension mode is enabled: 1/4/6
|
|
Access to third-party cameras
|
ONVIF; Panasonic; Sony; Axis; Arecont; Samsung
|
|
Compression standard
|
|
Video compression
|
AI Encoding; H.265+ Smart; H.265; H.264+ Smart; H.264
|
|
Audio compression
|
G.711a; G.711u; PCM
|
|
Red
|
|
Network protocol
|
HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; Filtro IP; FTP; DDNS; Servidor de alarma; P2P; Registro automático; Búsqueda de IP (compatible con cámara IP, DVR, NVS, etc.)
|
|
Mobile phone access
|
iOS; Android
|
|
Interoperability
|
ONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome; Firefox; IE 9 o posterior
|
|
Network mode
|
One-way mode
|
|
Recording playback
|
|
Recording mode
|
General, motion detection; smart; alarm; POS
|
|
Recording playback
|
Up to 4 channels
|
|
Backup method
|
USB device and network
|
|
Playback mode
|
Instant Playback, General Playback, Event Playback, Tag Playback, Smart Playback (Face and Motion Detection)
|
|
Alarm
|
|
General alarm
|
Motion detection; alarm box; external camera alarm; network alarm; PIR alarm
|
|
Anomaly alarm
|
Error (no disk, disk error, low space, low quota; network disconnect; IP conflict; MAC conflict); video loss; video tampering; camera offline
|
|
Smart alarm
|
Face detection; facial recognition; perimeter protection
|
|
Alarm link
|
Recording; snapshot (panoramic); external IPC alarm output; audio; buzzer; record, preset; email
|
|
Ports
|
|
Audio input
|
1 canal RCA 4 canales BNC (audio coaxial)
|
|
Audio output
|
1-channel RCA
|
|
Two-way conversation
|
Yes (shares the same audio input with the first channel)
|
|
HDD interface
|
1 SATA port, maximum capacity 16TB. Maximum hard drive capacity varies depending on ambient temperature.
|
|
RS-485
|
1
|
|
USB
|
2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
|
|
HDMI
|
1
|
|
VGA
|
1
|
|
Network port
|
1 (10/100 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power supply
|
12 VCC, 1,5 A
|
|
Energy consumption
|
<5 W (without hard drive)
|
|
Net weight
|
0.84 kg (1.85 lb)
|
|
Gross weight
|
1.37 kg (3.02 lbs)
|
|
Product Dimensions
|
260.0 mm × 237.8 mm × 47.6 mm (10.24" × 9.36" × 1.87") (Width × Depth × Height)
|
|
Packaging dimensions
|
333.0 mm × 89.0 mm × 315.0 mm (13.11" × 3.50" × 12.40") (Width × Depth × Height)
|
|
Operating temperature
|
–10 °C a +55 °C (14 °F a +131 °F)
|
|
Storage temperature
|
–20 °C to +60 °C (–4 °F to +140 °F)
|
|
Operating humidity
|
≤93% (relative humidity)
|
|
Installation
|
Rack or desk
|
|
Certifications
|
CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
|
