Derivative 4 outputs Class A 25dB Tecatel DER-CLA4S25

SKU
TECDERCLA4S25
Brands: Tecatel
€4.07 Tax included
Availability: In stock
24/48 Hours

ClassA series diverter 4 outputs/25dB Tecatel DER-CLA4S25

Diverter to distribute the signal in telecommunications facilities, in neighborhood communities or buildings. It is from the Class A series and has 4 outputs with F connection, including losses of 25dB. The device has low insertion losses.


The diverter has high quality zamac shielding, which makes it very resistant. In addition to an anti-corrosive nickel finish, which gives it much greater durability.

-
+

Technical Specifications of the Tecatel DER-CLA4S25 ClassA series 4 outputs/25dB shunt





Referencias References

DER-CLA4S25

Pérdidas de derivación (dB) Tap loss (dB)

25±1.0

25±1.5



Pérdidas de inserción (dB) Insertion loss (dB)

1.7

1.8

2.0

2.2

2.2

Aislamiento paso-derivación (dB) Out-Tap isolation (dB)



>20

Dimensiones (mm) Size (mm)



78x58x26

Peso (gr.) Weight (g.)



75

More Information
EAN 8430549029088
Hight 0.005
Length 0.003
Width 0.002
DTT System DTT & SAT Distribution
MANUFACTURER SERIES DTT F-connector
Color Silver
TV-SAT Distribution Equipment Diverter
Entorno Interior
TV-SAT Distribution Connection F
Outputs 4
Cut channel 48
Input signal FI, UHF, VHF
Insertion Loss (dB) 25
Current bypass Yes
Product Brand Tecatel
