Fibaro Double Smart Z-Wave Smart Device Controller

SKU
FIBFGS224
Brands: Fibaro
€64.69 Tax included
Availability: In stock
24/48 Hours

Z-Wave Double Smart Module Fibaro FGS-224

Module of two potential-free relays (dry contact) with timer function, to create a pulse, so it can be used to change a voltage of 230VAC or any type of DC power supply (5V, 12V, 24V,. ..).

Suitable for controlling any type of load, such as a boiler (connecting the dry contact instead of the thermostat), two automatic doors, two garage doors, two lights or other devices remotely.

Designed to activate and deactivate electrical devices wirelessly with Z-Wave Plus automation technology. Compact size for installation in junction boxes or recessed boxes, behind the switch. It is controlled by the Z-Wave network or by a simple wall switch.



-
+

Double Potential Free Relay Module to control devices remotely with Z-Wave Plus

What are the main features of the Fibaro FGS-224 Z-Wave Module?

FUNCTIONS:

  • Controls two lights / devices remotely Installs behind an existing switch (bistable or monostable)
  • ON / OFF function
  • Two potential free relays (door control, boiler, garage door, etc.)
  • Integrates the Z-Wave 500 series chip 250% faster
  • Communication compared to standard Z-Wave
  • Devices Integrated scene trigger mechanism (via S2)
  • Security communication and notification classes
  • Diode configuration menu
  • Supports secure mode (Z-Wave Network Security) encrypted with AES-128 encryption
  • Integrated Z-Wave Network Coverage Tester
  • OTA software update (depends on controller)
  • Larger terminal blocks for easier wiring
  • Rounded shape to meet the highest standards
  • Small, discreet and aesthetic
  • Ease of use and installation

TECHNICAL CHARACTERISTICS:

  • Module type: Z-Wave receiver
  • Power supply: 100 - 240V ~, 50 / 60Hz or 24 - 30 Vdc
  • Wiring: 3 wires, neutral required (230V)
  • Maximum power:
    • Maximum current per output: 6A / 110-240V ~, 50/60Hz (differs depending on the type of load)
    • Total maximum current: 9.5A / 110-240V ~, 50/60Hz (differs depending on the type of load)
  • Frequency: 868.42 Mhz
  • Transmission distance: 50m free field, 40m indoors (depends on building structure)
  • Signal strength: 1mW
  • Dimensions: 42.5mm x 38.25mm x 20.3mm (L x W x H)
  • Operating temperature: 0-35 ° C
  • Standards: CE, ROHS, 2011/65 / EU, 2014/53 / EU, 2015/863, ZWAVE PLUS
More Information
EAN 5902701702090
Hight 0.100
Length 0.060
Width 0.100
System Z-Wave
SERIE Actuators
Color Black
Automation Relay
Product Brand Fibaro
