Tecatel's FTP6CUN data cable is a category 6 cable composed of an internal conductor of copper or Cu, insulation of high density thermoplastic polyethylene or HDPE.
This data cable is perfect for the installation of data networks, such as internet connection, surveillance camera installations of balums and installations of porters and video door phones.
Tecatel's FTP6CUN Data Cable is a Category 6 outdoor data cable in black consisting of an inner Cu composite and an HDPE outer cover.
What technical features does the FTP6CUN data cable have?
4 Pair Braided Cable
Polyethylene separator to increase NEXT, ELFEXT and RL bandwidth
Solid internal conductor AWG23
Outdoor HDPE
Packaged in wooden coil
Length Marking
Guaranteed performance at 250 MHz
Tear strand for easy peeling
What is the attenuation of the tecatel data cable?
This CAT 6 data cable has the following attenuation at 100 meters:
Frecuencia
Atenuación/100m
1 MHz
- dB
4 MHz
3,5 dB
10 MHz
5,8 dB
16 MHz
7,4 dB
20 MHz
8,3 dB
31,25 MHz
10,5 dB
62,5 MHz
15,2 dB
100 MHz
19,5 dB
What is a data cable used for?
The Tecatel FTP6CUN data cable can be used for various installations. This cable can be used for the installation of a data network, such as the internet connection, for the installation of a circuit of video surveillance by balums or for the installation of a doorman or video entry system.
How to make our own data cable?
To make the connection of a data cable we need the cable in question, RJ45 connectors, a crimpadora to realize the fixation of the connector to the cable and a peeler for data cables.
