Full C Band PLL LNB with F Connection from JRC
1-output Single C-band LNB. 3.4 – 4.2 GHz input and 950 – 1750 MHz working frequency.
C-band LNB are used for television broadcasting services via satellite that are distributed to the customer in exchange for a periodic subscription.
It has low noise figure and low power consumption. Connection F.
Technical Specifications of the JRC Full C Band PLL LNB with F Connection
Model
NJS8486H
Rx working frequency
3.4 - 4.2 GHz
Local oscillator frequency
5.15GHz
Maker
NJRC
IF Frequency
950 - 1750MHz
IF connector
Type F (75Ω)
Stability
+/- 10ppm
| Item |
Specifications |
| Input Interface |
Waveguide, CPR229 (with Groove) |
| Output Interface |
N-type, female (50 ohm) [Model No.: NJS8486HN/87HN/88HN] |
| F-type, female (75 ohm) [Model No.: NJS8486H/87H/88H] |
| Noise Temperature (Ta.: +25 °C) |
15 K typ., 30 K max. |
| Linear Gain (Ta.: +25 °C) |
59 dB min., 66 dB max. |
| Local Stability |
+/-10 ppm (Ta.: -40 to +60 °C) |
| L.O. Phase Noise |
-70 dBc/Hz typ. @ 100 Hz |
| -80 dBc/Hz typ. @ 1 kHz |
| -85 dBc/Hz typ. @ 10 kHz |
| -95 dBc/Hz typ. @ 100 kHz |
| Spurious |
a) -140 dBm max.
at input, Fixed frequency spur, unrelated to test CW signal (Measured at specified IF band). |
b) -55 dBc max.
with test CW signal -10 dBm IF output (Measured at specified IF band). |
| Output V.S.W.R. |
2.5 : 1 max. |
| Power Requirement |
+24 VDC (+12 to +24 VDC) |
| Current Drain |
350 mA max. |
| Temperature Range (ambient) |
-40 to +60 °C (operating), -40 to +80 °C (storage) |
| Waterproof/Dustproof (IP Code) |
IP 67 |
Dimension & Housing
( without Interface Connectors ) |
80.8 mm (L) x 99.6 mm (W) x 76 mm (H) |
| [3.18" (L) x 3.92" (W) x 2.99" (H)] |
| Weight |
800 g [1.76 lbs] |
More Information
| Hight |
0.000 |
| Length |
0.000 |
| Width |
0.000 |
| System SAT |
LNB |
| MANUFACTURER SERIE SAT |
F Connector |
| Color |
White |
| LNB type |
Band C |
| Output number |
1 (Single) |
| Product Brand |
JRC |
