Housing Internal Amplifier 3 outputs

SKU
TEL553001
Brands: Televes
€34.51 Tax included
Availability: In stock
24/48 Hours

Housing Amplifier 3 outputs (2s+TV) + c. passive return 553001

This device has 1 input and 3 outputs, with F connection. It is used when we want to expand the home television network.

You will be able to amplify the terrestrial and satellite band with passive return path. The TV signal has a higher gain to be able to connect to the TV directly (without installing an outlet). The gain can be controlled manually.

Compact in size and lightweight, it is presented in white. Its integrated switching power supply produces a 40% reduction in consumption compared to a common amplifier.

The amplifier can be installed screwed to the wall.

-
+

Technical Specifications of the Home Amplifier 3 outputs (2+TV) + c. passive return 553001



Output 3 (2+TV) (F)
Frequency range MHz 5...65 (RET) 88...862 950-2150
Gain dB -9
(-16 @ TV)
19
(11 @ TV)
21
(13 @ TV)
Regulation margin
profit
- 12 -
Equalizer - - -
Output level DIN 45004B Vout dBμV - 111 114
Noise figure dB - 4 3
Mains voltage/frequency V~/Hz 110...230/ 50...60
Total AC consumption W/mA < 3,2 / 57
Pass current DC S/E mA 300 máx
Protection index IP 20
Operating temperature range ºC -5 ... +45



553001

More Information
EAN 8424450252925
Hight 0.250
Length 0.030
Width 0.100
DTT System Amplificador TDT y SAT
MANUFACTURER SERIES DTT F-connector
Color Beige
Type Indoor home amplifier
Input signal FI, UHF, VHF
# Inputs 1
Outputs 3
Gain 21
Max. output level Ganancia (dB/uV) 114
LTE compatible No
Product Brand Televes
