The Johansson 2434 power supply is a high efficiency feeder working at 24V.
This power supply has 2 outputs, with protection against short circuits and indicate power LED.
This source can be installed on both wall and DIN rail.
The 2434 power supply allows 24v power to the devices of our facility that work in an active way, such as an amplifier.
| Outputs | - | 2 |
| Insertion loss | dB | 4 |
| Isolation between outputs | dB | 10 |
| AC input voltage/Frequency/Power | - | 230 V~ / 50 Hz / 4,8 W |
| DC output voltage | VDC | 24 |
| Output current | mA | 150 |
| Dimensions | mm | 110 x 94 x 41 |
A feeder is used to give current to the products that are active, that is to say they need additional energy to operate, such as an amplifier, that if it does not receive this extra power, it will not provide the gain that our signal needs to arrive correctly To our television.
| EAN | 2024360000010 |
|---|---|
| Hight | 0.100 |
| Length | 0.060 |
| Width | 0.080 |
| DTT System | DTT Power Supply |
| SERIES DTT | 24Vdc |
| Color | White |
| Power supply | Mast Amplifier |
| Feed Power | 24 Vc |
| Current (mA) | 150 |
| Outputs | 2 |
| Product Brand | Johansson |
