Manageable Switch 48 Ports 1Gb 16 2.5Gb POE and 4 SFP+ 10Gb 740W from Engenius

SKU
ECS2552FP
Brands: EnGenius
€856.68 Tax included
Free shipping
(Iberian Peninsula)
Availability: On request
1 to 7 days

Engenius 48-Port 2.5Gb POE+ and 4SFP+ 10Gb 740W Managed Switch

 This manageable switch has 48 2.5Gigabit ports and 4 10Gb SFP+ slots. The 48 ports are POE+ providing a maximum power of 740W. The 4 SFP+ uplink ports offer a wealth of management options, easy setup and monitoring. This switch is ideal for powering VoIP phones, IP cameras, access points in large companies.

The ECS2552FP enables full-featured Layer 2+ switching.

Of the 48 ports that the switch has, 32 of them are Gigabit and the remaining 16 are 2.5Gigabit POE ethernet ports. The 4 SFP+ uplink ports are double speed (10G fiber). Standard 802.3af/at PoE on all ports with up to 740W total consumption, with which you can power cameras, phones, access points, etc.

Advanced PoE features for surveillance: Extended PoE mode, PD lifesaver, and continuous PoE power.

They are managed in the cloud, so you don't have to be at the physical facility to make changes to the facility.

Package content:

*1 x Managed Gigabit Switch

*1 x quick installation guide

*1 x power cord

*1 x RJ45 console cable

*1 x rack mounting kit

-
+

Technical Specifications of the Engenius 48-Port 2.5Gb POE+ and 4SFP+ 10Gb 740W Managed Switch

Technical Specifications

Port Standards

802.3u 100Base-TX Ethernet 802.3ab 1000Base-T Ethernet 802.3bz 2.5G/5GBase-T Ethernet 802.3x Full-Duplex Flow Control

Network Ports

32×10/100/1000 Mbps Ports 16×100/1000/2500 Mbps Ports 4x SFP+ Ports

Switching Capacity

224 Gbps

SDRAM

512 MB

Flash Memory

128 MB

PoE Capable Ports

1-48

Total PoE Budget

740W

Power Source

100 ~ 240VAC, 50-60Hz

Physical Interface

LED Indicators

Power LED Fault LED PoE Max LED LAN Mode LED PoE Mode LED

Ports

Link/Activity/Speed (per Ethernet port) Link/Activity/Speed (per SFP slot)

L2 Features

Network Management

EnGenius Cloud ezMaster Local Web GUI

MAC Address Table

32K

Jumbo Frame

10K

Multicast Group

Max 256 groups

MLD Snooping

MLD Snooping: v1

QoS-number of Priority Queues Supported

Queue 8

Trust Mode

Cos/802.1p DSCP CoS/802.1p-DSCP

Scheduling Mechanism

Strict / WRR/ Strict + WRR

Bandwidth Control

Port-based bandwidth control (Ingress/Egress)

Port Security

Max. 256 Entries

Access Control List (ACL)

MAC Based ACL IPv4/IPv6 Based ACL ACL Binding Timebase ACL

Web Graphical User Interface (GUI)

HTTP IPv4 / IPv6 HTTPS IPv4 / IPv6

SSL Certificate

Certificate/Key Import

SNMP

SNMP v1/v2c/v3 Support

RMON

RMON 1,2,3,9

System Time

Time Setting/Daylight saving

Common L2 Features

802.1d Spanning tree Loopback Detection Multicast Filtering IGMP Multicast Forwarding IGMP Snooping MLD Multicast Forwarding 802.1Q VLAN tagging 802.3x flow control 802.3ad Link Aggregation IPv4 DHCP Relay IPv4 DHCP Snooping IPv4 DHCP Snooping Source MAC Address Check-up ARP Packet Validation (additional validation checks) Voice VLAN Port-based VLAN Protocol-Based VLAN CoS Mapping 802. 1X Radius Authentication Protocol IEEE 802. 3az Energy Efficient Ethernet (EEE) Command Line Interface (CLI) SSH Server Telnet Server TFTP Client Configuration Upgrade/ Backup Simple Network Time Protocol (SNTP) SYSLOG 802.1d Spanning tree

L3 Features

Multiple IP Interface

20 IPv6 address

ARP Table

Max. 192 ARP entries

Static ARP

Static 192 ARP entries

IPv4 Static Route

Max. 63 entries

IPv6 Static Route

Max. 21 entries

Environmental & Physical

Temperature Range

Operating: 32°F to 122°F (0°C to 50°C)

Humidity (Non-Condensing)

5% – 95%

Dimensions & Weight

ECS1552FP Device

Weight: 5.9Kg Width: 310mm Length: 440mm Height: 44mm

Package Contents

1x ECS Managed Gigabit Switch 1x Quick Installation Guide 1x Power Cord 1x RJ45 Console Cable 1x Rack Mount Kit

Warranty

2 Years

More Information
Hight 0.000
Length 0.000
Width 0.000
RED - System POE+
RED - SERIE 48 Ports
Color Black
Network Equipment Switch
Ports 48
Data Speed Gigabit (10/100/1000Mbps)
PoE Yes
Product Brand EnGenius
