LNB Monoblock Single 6º for Astra 19º and Hotbird 13º

SKU
ANTIV205150
Brands: Inverto
16% Discount for professionals
Inverto
Availability: Out of stock
Consult
Be the first to review this product

LNB Monoblock 6º Black Pro of 0.2dB 40mm

Inverto LNB Monoblock Single 6º IDLB-SINM40-MNOO6-8PP converter for the reception of Astra 19º and Hotbird 13º satellites on an 80cm satellite dish.

1-output LNB for distribution to a single satellite receiver, manufactured to the highest industry standards for high-definition transmissions with superior performance, offering a gain of 50~62dB and a minimum noise figure of 0.2dB.

This Inverto Monoblock converter has a very low consumption and an always flat and stable frequency response.

Inverto Monoblock Single 6º LNB with 40mm diameter to install on 80cm satellite antenna.

What are the main features of the Inverto Monoblock Single 6º LNB?

  • Low noise level compatible with HDTV-DVBS2
  • Low noise figure of 0.2 dB
  • Low energy consumption
  • Very high performance Cross-Pole
  • Very high frequency stability
  • Gain: 50~62dB

What technical specifications does the Inverto Monoblock Single 6º LNB converter have?

Low Band Input Frequency Range 10.7 ~ 11.7 GHz
Low Band Output Frequency Range 950 ~ 1950 MHz
Low Band LO Frequency 9.75 GHz
High Band Input Frequency Range 11.7 ~ 12.75 GHz
High Band Output Frequency Range 1100 ~ 2150 MHz
High Band LO Frequency 10.6 GHz
Noise Figure 0.2 dB Typ. (0.7 dB Max.)
LO Initial Accuracy +/- 1.0 MHz Max.
LO Temperature Drift +/- 3.0 MHz Max.
Phase Noise (@ 10 kHz) - 90 dBc / Hz Max.
Conversion Gain 50 ~ 62 dB
Gain Ripple (Over 26 MHz Bandwidth) +/- 0.75 dB
Gain Variation (Over Full Band) +/- 4 dB Max.
Image Rejection 40 dB Min.
1 dB Compression Point (@ Output) 0.0 dBm Min.
Control: Satellite A/B Selection DiSEqC 1.0 (Sat A* = HOTBIRD 13° East, Sat B = ASTRA 19.2° East)
Cross Polarization Isolation 22 dB Min.
Output VSWR 2.5 : 1
In-Band Spurious - 60 dBm Max.
Current Consumption 150 mA Max. @ 11 ~ 20 V
Operating Temperature - 30 °C ~ + 60 °C
Output Impedance 75 Ω
Output Connector F-Type (Female)
Weight 270 g
Recommended Dish Size 75-85 cm (F/D = 0.6)
Monoblock Mounting Bracket 40 mm
More Information
More Information
EAN 5453001045917
Hight 0.130
Length 0.090
Width 0.100
System SAT LNB
SERIE SAT Single
Color Black
LNB type Universal
Output number 1 (Single)
Noise level 0,2
Focus number Monoblock 6º
Gain >50 db
Product Brand Inverto
