NVR Recorder 16 IP Channels 8Mpx POE from Hikvision On request
Delivery: 1 to 7 days
16 Channel 8Mpx POE IP Recorder
16-channel NVR recorder with a maximum resolution of 8Mpx in which you can connect CCTV security IP cameras. The recorder supports 160Mpbs bandwidth and H.265+/H.265/H.264+/H.264 video compression.
It has 4K HDMI and VGA outputs . Its 16 ports are POE, it has space for 2 3.5” SATA hard drives of up to 6TB and is ONVIF compatible.
Package content:
*Hikvision recorder
*Mouse
*Power cord
*CD with manual and software
Technical Specifications of the 16-Channel 8Mpx POE IP Recorder
Brand Hikvision
Range HiWatch Series
Inputs for IP cameras LAN port up to 16 channels
Power over Ethernet 16 port PoE Switch IEEE802.3af/at (max. 75 W)
IP compatible cameras HIKVISION, ONVIF
Bidirectional audio 1 input / 1 RCA output
Video outputs 1 HDMI 4K, 1 VGA
Video compression format H.265+ / H.265 / H.264+ / H.264
Display resolution 3840x2160, 2560x1440, 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768
Decoding capacity 2CH @ 8 MP (25fps) / 4CH @ 4MP (30fps) / 8CH @ 1080p (30fps)
Total bandwidth 160 Mbps downstream / 160 Mbps upstream
Main Stream recording 8MP/6MP/5MP/4MP/3MP/1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarms 4 inputs / 1 relay
Recording method Manual, programmed, motion detection, alarm
External Backup USB memory / HDD USB / CD-RW USB / DVR-RW USB
Internal memory 2 SATA HDD 3.5" of up to 6 TB (not included)
Communication 2 x USB 2.0 / 1 x RJ45 10/100/1000 (Ethernet)
Remote access Web Browser, Smartphone App IVMS 4500 and PC Software IVMS 4200
Power 100-240 VAC, 50/60 Hz
Dimensions / Weight 52 (H) x 385 (W) x 315 (D) mm / 3.0 Kg (without HDD)
More Information EAN 6941264049173 Hight 0.440 Length 0.130 Width 0.380 SECURITY - SYSTEM IP SEGURIDAD - SERIE 8Mpx Included Mouse, Power supply Event notifier No No. CCTV Recorder Inputs 16 IP Audio in ports 1 Product Brand Hikvision
File Label Size Download Ficha Tecnica Grabador NVR 16 Canales IP 8Mpx POE de Hikvision 320.2 KB Download
