Optical distributor with 2 outputs FC / PC

Name: Optical distributor with 2 outputs FC / PC
Brand: INVACOM
SKU: ANTVS144604
Price: 35.47 EUR
Availability: InStock

SKU

ANTVS144604

Brands: INVACOM

€35.47 Tax included

Availability: On request

Delivery: 1 to 7 days

Be the first to review this product

Optical Distributor with 2 FC / PC outputs ANTVS144604 from Invacom.

The optical distributor VS144604 of Antares allows the distribution in 2 lines, although versions exist versions of 2,3,4,8,16 and 32 ways.

This distributor has a double window at 1310 and 1550 nm, also allows the direct connection of fiber optic cables.

The image may not match the item.

Details

The Optical Distributor VS144604 allows us to distribute a fiber optic signal over two lines.

What technical characteristics does the VS144604 dealer have?

Operating wavelength of 1310 and 1550 nm.
Thermal stability of ≤ 0,2dB.
Directivity of ≥ 50dB.
Insertion loss of 3.65dB and 4.0dB maximum.
Operating temperature -40 to 75 ° C.
FC connector on the input and PC on the output.
Dimensions 148 x 115 x 21 mm

What optical distributor do I use?

First you have to take into account how many lines I want to work or need, and once we have planned our installation, we must buy the distributor that best suits our installation.

What connectors does this distributor use?

It uses an FC connector, which is a fiber optic connector with a threaded body, which was designed for use in high vibration environments, and a polished PC (Flat), which is the most used in fiber optic connectorization.

More Information

More Information
EAN	8401314460412
Hight	0.250
Length	0.020
Width	0.120
Color	Black
RED - System	Fibra Óptica
RED - SERIE	FO Distribution
Product Brand	INVACOM
FO Distribution	FO Splitter
Entorno	Interior
