Power supply for rail DIN 12V and 4.5A for transmodulator TDX-420
Availability: On request
1 to 7 days
12V and 4.5A HDR-60-12 power supply
The HDR-60-12 power supply is a power supply that offers a voltage of 12V and 4.5A, perfect for powering the Terra TDX-420 transmodulator.
This power module is designed to provide adequate voltage to the transmodulator of the TDK series.
It also offers a switching mode technology and protection against short circuits and overloads.
The HDR-60-12 feeder allows to feed, thanks to its voltage of 12V and 4.5A to the transmodulators of the Terra TDK series.
What technical characteristics does the HDR-60-12 source have?
- Switched mode technology
- Protection against short circuits and overloads.
- DIN rail mounting
- Output: +12 V and 4.5 A max.
- Mains voltage: 100 V ÷ 240 V ~ 50/60 Hz
- Operating temperature range: -20o ÷ + 50o C.
What technical characteristics does the TDK-420 transmodulator have?
- Conversion of DVB-S / S2 signals to DVB-T standard COFDM.
- Conversion of multiple signals from two satellite transponders to 2 neighboring DVB-T multiplexes.
- Possibility of creating a DVB-T multiplex from two different satellite transponders.
- Selectable channels and services.
- Easy control through the RJ-45 port.
- Management through the internet.
- Access to the history of events (logs).
- Automatic gain control (AGC).
More Information | EAN | 8430549059535 |
|---|
| Hight | 0.150 |
|---|
| Length | 0.060 |
|---|
| Width | 0.130 |
|---|
| System SAT | SAT Supply |
|---|
| SERIE SAT | TDX |
|---|
| Length | 0.5 meters |
|---|
| Color | Black |
|---|
| Product Brand | Terra |
|---|
| File | Label | Size | Download |
 | Ficha técnica de la fuente de alimentación HDR-60-12 | 344.7 KB | Download |
