Quadruple Video/Audio Converter to DTT in Standard Definition (SD) from Promax

Name: Quadruple Video/Audio Converter to DTT in Standard Definition (SD) from Promax
Brand: Promax
SKU: PRODT-504B
Price: 4719 EUR
Availability: InStock

SKU

PRODT-504B

Brands: Promax

€4,719.00 Tax included

Availability: On request

Delivery: 1 to 7 days

Be the first to review this product

Quadruple Video/Audio Converter to DTT in Standard Definition (SD) from Promax

We present you an excellent and economical solution to face the SD blackout in large complexes such as hotels, so that you can continue using the old televisions, even if they are not HD.

This converter takes up to 8 High Definition DTT services and modulates them into 1 DTT mux in SD format, so we can use old SD televisions. The modulator is installed in cascade and we can install as many as necessary to increase the channel offering.

canales.

We will preserve the original HD channels if we mix the output with the original antenna source, coexisting in the same installation the old televisions with the modern televisions with an HD receiver.

This kit is installed in the headboard allowing you to enjoy all the high definition channels on all televisions, including old ones, even if they do not have an HD receiver without having to do any work, using the same televisions, taking advantage of the previous wiring and all in a very simple and fast.

Details

Technical Specifications of the Promax Quad Video/Audio to DTT Converter in Standard Definition (SD)

SPECIFICATIONS	DT-504B
A/V inputs Guy Supported video formats	4 RCA inputs, 3 connectors per input (video, left audio and right audio). PAL, NTSC.
MPEG-2 Encoder Bitrate Video Bitrate Audio Editable parameters"	According to DVB-T modulation parameters. From 32 to 384 kbits/s selectable. Service Name, Service ID, Video PID, Audio PID, PMT PID.
DVB-T Modulator Carriers Channel Width Guard Interval Code Rate Constellation Spectral Inversion	2k, 8k. 7MHz, 8MHz. 1/4, 1/8, 1/16, 1/32. 1/2, 2/3, 3/4, 5/6, 7/8. QPSK, 16-QAM, 64-QAM. ON, OFF.
RF output (DVB-T) Connector Output frequency MER	1 DVB-T multiplex. 75 Ω Type-F, Female. Adjustable between 474 and 875 MHz (1 Hz steps). Optional 170 to 650 MHz output. > 37 dB.
Setting	Through the DT-800 Control Unit locally or remotely (PC). See DT-800.
Feeding Supply voltage and maximum consumption	Through the DT-800 control and power unit. +12V 0.99A; +5V 0.67A.
Mechanical characteristics Dimensions Weight Assembly	50 (W) x 262 (H) x 230 (D) mm. 1,170 kg. In the DT-900 rack or wall structure.

More Information

More Information
Hight	0.000
Length	0.000
Width	0.000
DTT System	Cabeceras
MANUFACTURER SERIES DTT	F-connector
Color	Silver
Type	Transmodulator
Output signal	DVB-T
# Inputs	4
Outputs	1
Output mux	1
Common interface	No
Product Brand	Promax
