Radial Active IF Multiswitch 9 Inputs x 32 Outputs Terra
Active Radial Multiswitch with 8FI + 1Terrestrial Inputs and 32 Outputs TE-MR932L
This multiswitch is capable of managing up to 8 different satellite polarities (2 full satellites: H/L, H/H, V/L, V/H), sending to each output the polarity requested by the user. The output is mixed with the terrestrial signal to distribute it to 32 users. So it has 9 inputs and 32 outputs. It can be used for small installations as well as for large collectivities.
The advantage of a multiswitch is that each home has complete access to radio, DTT and all satellite polarities through a single cable, without having to install a satellite dish per user.
A multiswitch works as a matrix, so that it redirects to each house the input signal demanded at each moment. The receiver, depending on the TV channel selected by the user, will send a voltage through the coaxial cable for polarization (13Vdc for vertical and 18Vdc for horizontal) and a tone for the band (0KHz for low and 22KHz for high).
The MR932L offers high performance, stability and durability.
