main product photo

Splitter F.O.1260...1650nm “SC/APC” 8D 10dB

SKU
TEL234450
Brands: Televes
€46.97 Tax included
13% Discount for professionals
Televes
Availability: On request
1 to 7 days
Be the first to review this product

Splitter óptico 8 outputs and 10 dB Televes. Ref. TEL234450.

Range of optical distribution networks for FTTx, PON, etc., ideal for mounting in boxes and racks (tray type accessories). Its main advantages are:

  • High reliability.
  • Low insertion loss.
  • High uniformity between outputs.
  • Made of single mode fiber (SM) of 900μm.
  • Meet ITU-T standards-G657A1.

Applications for telecommunications networks (FTTx, PON systems LAN, WAN).

-
+

Main features:

  • High reliability.
  • Low insertion losses.
  • Very Low PDL (polarization sensitivity).
  • Excellent uniformity.
  • Design and compact dimensions.
  • SC / APC Connectorization.
  • Made with 900 microns SM fiber, which gives ease of handling and resistance.
  • According to ITU-T G657A1, which provides its fibers a very small turning radius.

Applications:

  • Telecommunications networks (FTTH PON systems LAN, WAN).
Referencia 233750  233950  234450  234550  234650
Nº de salidas No. of outputs   2 4 8 16 32
Conectores ópticos de entrada y salida Input & output connectors Type SC/APC
Fibra Fiber Type Monomodo / Single-mode G657A1
Diámetro de la fibra Fiber diameter μ 900
Longitudes de onda de trabajo Working wavelength nm 1260 ... 1650
Pérdidas de inserción Insertion loss (IL) dB ≤ 4.1 ≤ 7.5 ≤ 10.5 ≤ 13.5 ≤ 17.5
Pérdidas de retorno Return loss (RL) dB ≥ 55
Uniformidad Uniformity dB ≤ 0.6 ≤ 0.8 ≤ 0.8 ≤ 1.2 ≤ 2
Pérdidas de polarización Polarization dependent loss (PDL) dB     0.3
More Information
More Information
EAN 8424450184899
Hight 0.295
Length 0.041
Width 0.146
REDES - System Fibra Óptica
REDES - SERIE FO Distribution
Product Brand Televes
FO Distribution FO Splitter
Entorno Interior
