Single-channel DTT amplifier for T03/T12 SELECTIVE channel 38

SKU
TEL509812C38
Brands: Televes
€88.94 Tax included
Availability: In stock
24/48 Hours

Single channel DTT amplifier for selective T12.Ref. 509812 of Televes.


Single channel amplifier for DTT frequency amplification. This amplifier is used together with the rest of the single-channel amplifiers that form a headend. The rail is necessary for its operation (it can be installed on a DIN rail, chest or rack) and the power supply. It has a very high adjustable gain.

With the T.12 single-channel amplifiers, Televés has achieved a product that provides unbeatable performance in signal processing, with precise and simple frequency adjustments. The T.12 modules are manufactured on state-of-the-art robotic lines and are subjected to the strictest quality controls, a guarantee of unprecedented reliability and stability. Prepared to adapt to the incipient relocation of the digital dividend, this product bears the Televes LTE Ready seal.

This amplifier belongs to channel 38. If you need a different channel, please contact us.

-
+

Technical Specifications of the Single Channel TDT Amplifier for selective T12.Ref. 509812 of Televes.



Features:

  • Total compatibility with the previous model T.03 as well as its power source
  • High reliability. ., thanks to its fully robotized manufacturing
  • Considerable improvement in the design of . Shielding
  • System ... modular and extensible
  • Power up to 24 modules, through its Power Supply
  • Remote Power previous



Frequency margin MHz 470...890
Bandwidth MHz CCIR 8
NTSC 6
Gain dB 50
Gain regulation 30
AGC dynamic margin -
Equalizer -
Max.output level dBμV A EN 50083-5 125
D EN 50083-5 118
dBmV A EN 50083-5 65
D EN 50083-5 58
Max. current input mA 100
Power supply Vdc 24
Current consumption mA 95
Flatness dB <2
Rejection CCIR dB Rn±1 >18
Rn±2 >50
Rn±3 -
NTSC Rn±1 10
Rn±2 >40
Rn±3 -
Protection Level IP 20



More Information
EAN 8424450159798
Hight 0.000
Length 0.000
Width 0.000
DTT System DTT Amplifier
MANUFACTURER SERIES DTT T12
Color Silver
Type Single channel amplifier
Input signal UHF
LTE compatible No
Current bypass Terrestrial
Product Brand Televes
Write Your Own Review
You're reviewing:Single-channel DTT amplifier for T03/T12 SELECTIVE channel 38
Your Rating
File Label Size Download
pdf Ficha Técnica Amplificador Monocanal TDT para T03/T12 SELECTIVO canal 38 292.9 KB Download
