Shunt Nevoswitch 5x5x5 "F " 20dB . Ref . 714903 Televes
This device complements nevoswitch multiswitch range , so that the installation is achieved expand to a larger number of users by optimizing the signal will reach each.
Highlights:
Zamak chassis that makes them immune to radiation.
scalable system for star topologies and waterfall.
Independent adjustment of the output level to each user (except range QUAD Compatible) .
ECO low-power mode .
ECO system has the consumption of the installation is reduced with decreasing the number of connected users.
Characteristics:
independent amplification lines .
Configurable.
Small size and compact design.
Multiple power options ( Jack , line VL , user input or terrestrial and output connectors ) independent level control on each output
| EAN | 8424450173428 |
|---|---|
| Hight | 0.161 |
| Length | 0.044 |
| Width | 0.135 |
| System SAT | SAT Multiswitch |
| SERIE SAT | Nevoswitch |
| Type | Cascading |
| # Input satellites | 4 |
| # Terrestrial inputs | 1 |
| # Inputs | 5 |
| #User outputs | 5 |
| Loos (dB) | 20 |
| LNB type | Quattro |
| Product Brand | Televes |
