UHF-SAT Indoor Amplifier 1in/1out LTE 5G Ikusi

Name: UHF-SAT Indoor Amplifier 1in/1out LTE 5G Ikusi
Brand: Ikusi
SKU: IKU3590
Price: 35.79 EUR
Availability: InStock

SKU

IKU3590

Brands: Ikusi

€35.79 Tax included

Availability: In stock

Delivery: 24/48 Hours

Be the first to review this product

Indoor Terrestrial and Satellite Amplifier LTE 5G ATP-190-C48 Ikusi 3590

Indoor home amplifier for Terrestrial and Satellite signals, adapted to the 2nd Digital Dividend with integrated 5G LTE filter. It has 1 input and 1 output, type F, and admits return channel and current path to power the LNB.

Compact amplifier designed to install in single-family homes. It offers 18dB of gain in Terrestrial and 22dB in Satellite; Maximum output supports 106dBμV for Terrestrial and 112dBμV for Satellite. Includes gain adjustment potentiometer for Terrestrial.

Its installation is very simple, it includes an adapter for fixing to the wall.

Details

Ikusi ATP-190-C48 Indoor Home Amplifier for Terrestrial and Satellite LTE 5G with 1 Input and 1 Output

What technical specifications does the Ikusi 3590 Indoor Amplifier have?

Model: ATP-190-C48
Reference: 3590
Frequencies: 47-694 MHz / 950-2400 MHz
Input: 1
Departure: 1
Gain: Terr> 18 dB / Sat> 22 dB
Gain regulation: Terr> 10 dB
Output level: Terr 106 dBμV / Sat 112 dBμV
Return path frequency: 5-30 MHz
Noise figure: Terr <5 dB / Sat <6 dB
Mains voltage: 100-240 Vac
Pass current: 500 mA
Consumption: <3 W
Dimensions: 135x70x30 mm

More Information

More Information
EAN	8435136435907
Hight	0.170
Length	0.040
Width	0.110
DTT System	Amplificador TDT y SAT
MANUFACTURER SERIES DTT	F-connector
Color	White
Type	Indoor home amplifier
Entorno	Interior
# Inputs	1
Outputs	1
Gain	18
Max. output level Ganancia (dB/uV)	106
LTE compatible	No
Current bypass	Satellite, Terrestrial
Product Brand	Ikusi
