This power supply is used for door entry or video door entry systems with a VIP system. It has a 110Vca/230Vca input and a 55Vdc output, supplying a total power of 100W.
It can be applied on a DIN rail, with up to 6 DIN modules. Made of white coated plastic, it is very compact in size and light in weight (only 347g).
| IP (VIP) 110-230VAC/55VDC, 100W POWER SUPPLY UNIT | |
| MAIN FEATURES | |
| Applicable to DIN rail | Yes |
| Number of DIN modules (n°) | 6 |
| HARDWARE SPECIFICATIONS | |
| Product weight (g) | 347 |
| GENERAL DATA | |
| Height (mm) | 99 |
| Width (mm) | 93 |
| Depth (mm) | 53 |
| Type of finishing materials | Plastic |
| Product color | White |
| COMPATIBILITY | |
| Vip system | Yes |
| AUDIO/VIDEO FEATURES | |
| Audio/video system | Yes |
| ELECTRICAL SPECIFICATIONS | |
| Power supply | 220÷240VAC |
| Direct voltage output A (VDC) | 55 |
| Maximum current absorption (mA) | 1,3 |
| Maximum power delivered (W) | 100 |
| GENERAL FEATURES | |
| DIN modules (no.) (n°) | 6 |
| DIN rail mounted | Yes |
| EAN | 8023903209419 |
|---|---|
| Hight | 0.100 |
| Length | 0.050 |
| Width | 0.080 |
| ACCESOS - SISTEMA | Systems Supply |
| ACCESOS - SERIE | Spare |
| Color | White |
| Type | Power supply |
| Product Brand | Comelit |
| File | Label | Size | Download |
|---|---|---|---|
 | Ficha Técnica del Alimentador de Sistema VIP 100W | 1 MB | Download |
