Wall Rack Cabinet 19" 12U Depth 450 with Accessories GTLAN

SKU
GTL31GTM12F4
Brands: GTlan
€191.74 Tax included
Availability: On request
1 to 7 days

19" 12U F450 Wall Rack Cabinet with Accessories GTLAN 31GTM12F4

19" L type wall-mounted rack cabinet with 12U height and 450mm depth. It has dimensions of 634x600x450 mm and supports a maximum load of 60kg. This wall cabinet is ideal for small installations where a robust quality cabinet is required.

Made of 2mm cold-rolled SPPC steel and 5mm tempered glass front door with a change-of-direction opening system. Its dimensions make it easy to install in small spaces where a floor cabinet cannot fit. Thanks to its Drill & Go design, installation can be done by one person without help.

Accessories included with this wall-mounted rack cabinet: fixed tray, 19 "power strip, ceiling fan and screw / nut kit.

-
+

Wall rack cabinet 19" 12U and 450mm deep, with accessories included.

Click here to discover the entire range of GTLAN rack cabinets.

What technical specifications does the GTLAN 31GTM12F4 rack have?

Capacity 12U
Profile L type
Maximum load 60 kg
Material 5mm tempered glass, 2mm high quality cold rolled SPPC steel
Clamping profiles 4 pcs adjustable in depth (2mm thick)
Front door 5mm tempered glass with rectangular lock
Back Smooth with Drill&Go binding
Lateral Detachable smooth with plastic closures (optional round side lock)
Wired input Upper and lower
Finish Fine-grained powder coating
Color Black RAL - 9004
Dimensions 634x600x450 mm
Packaging Dimensions 645x610x460 mm
Weight 23.75 kg
Packaging Weight 26 kg
Accesories Fixed tray + Power strip 19" + Ceiling fan + kit screws/nuts
Watertightness IP20
Normative EIA/ECA-310-E, IEC 60297, ETSI/EN 300 119, RoHS 2011/65/UE Y CE
Cubic capacity with pallet 0.202 m3

More Information
EAN 8435481002441
Hight 0.660
Length 0.620
Width 0.480
Color Black
Units 12
Width 19"
Depth 450 mm
Rack type Wall
Rack accessories Other accessories, Plates, Strips, Ventilation units
Frame Wall
Product Brand GTlan
